FL12 WH
The FL12 WH was designed and perfected by the DeepCool team to provide a unique light effect fan with high performance, low noise, and outstanding quality.
COLOR
white
MODEL
FL12 WH
A LUMINOUS HALO
LUMINOUS HALO
Light-optimized design using 36 pcs ARGB Gen2 lamps surround the frame to create a vivid light brightening your PC.
PERFORMANCE-ORIENTED
Each fan is equipped with a 3-Phase, 4-Pole, and 6-Slot motor, and each motor has precision wiring like an industrial art to achieve highly consistent performance and quality.
500-2150 RPM±10%
55 CFM
2.82 mmAq
≤32 dB(A)
DURABLE MATERIALS
The entire structure and dynamic balance are further strengthened by using an enhanced composite material based on PBT for the fan blades and frames.
SECURE CONNECTION
The 8-pin connectors, integrated with PWM and ARGB SYNC, provide a more accessible and safer user installation experience.
REDUCED VIBRATIONS
Full-coverage rubber pads at each corner guarantee minimal fan vibration and ensure that noises resulting from uneven mounting pressure are minimized.
Technical Spec
Fan Dimensions120×120×25 mm(L×W×H)
Net Weight166 g
Fan Speed500~2150 RPM±10%
Fan Airflow55 CFM
Fan Air Pressure2.82 mmAq
Fan Noise≤32 dB(A)
Fan Connector4-pin PWM
Bearing TypeFluid Dynamic Bearing
Fan Rated Voltage12 VDC
Fan Rated Current0.15 A
Fan Power Consumption1.8 W
LED TypeAddressable RGB LED
LED Connector3-pin(+5V-D-G)
LED Rated Voltage5 VDC
LED Power Consumption2.75 W
EAN6933412711070
P/NR-FL12-WHAPN1-G
